參數資料
| 型號： | 0002066143 |
| 廠商： | MOLEX INC |
| 元件分類： | 終端 |
| 英文描述： | BRASS, TIN (100) FINISH, WIRE TERMINAL |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 1/2頁 |
| 文件大小： | 33K |
| 代理商： | 0002066143 |
This document was generated on 11/05/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Active
Overview:
Description:
1.57mm (.062") Diameter, Standard .062" Pin and Socket Crimp Terminal, Series 1854,
Male, with Selective Gold (Au) Plated Brass Contact, Tin (Sn) Plated Crimp Area, 24-30
AWG, Reel
Documents:
General
Product Family
Crimp Terminals
Series
Overview
Standard .062"
Product Name
Standard .062"
Physical
Gender
Male
Material - Metal
Brass
Material - Plating Mating
Gold
Material - Plating Termination
Tin
Packaging Type
Reel
Plating min: Mating (in)
30
Plating min: Mating (m)
0.75
Plating min: Termination (in)
100
Plating min: Termination (m)
2.5
Termination Interface: Style
Crimp or Compression
Wire Insulation Diameter
1.02-2.29mm (.040-.090")
Wire Size AWG
24
Wire Size AWG
26
Wire Size AWG
28
Wire Size AWG
30
Wire Size mm
N/A
Material Info
Old Part Number
1854-(228)
Reference - Drawing Numbers
Sales Drawing
SD-1854-*
Series image - Reference only
ELV and RoHS
Compliant
Not Reviewed
Not Reviewed
Need more information on product
environmental compliance?
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
1854 Series
Application Tooling
| FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Terminator Die
Manual Extraction
Tool
Hand Crimper -
DISTRIBUTION
ONLY
Hand Crimp Tool
Mini-Mac
Applicator
Japan
Description
Product #
Hand Insertion Tool 0011020001
