參數資料
| 型號： | 0002092103 |
| 廠商： | MOLEX INC |
| 元件分類： | 終端 |
| 英文描述： | BRASS, TIN (20) FINISH, WIRE TERMINAL |
| 封裝： | HALOGEN FREE AND ROHS COMPLIANT |
| 文件頁數： | 2/4頁 |
| 文件大小： | 146K |
| 代理商： | 0002092103 |
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any non-
product compliance questions.
Search Parts in this Series
1190
Series
Use With
1619
Plug or Receptacle Housing,
1545
Plug or Receptacle Housing,
1396
Plug or Receptacle Housing,
1490
Plug or Receptacle Housing,
2629
Plug or Receptacle Crimp
Housings, 1261 Plug or Receptacle
Housing, 1292 Plug or Receptacle
Housing, 1360 Plug or Receptacle
Housing, 1375 Plug or Receptacle
Housing, 3191 Plug or Receptacle
Housing, 2163 Plug or Receptacle
Housings
Application Tooling
| FAQ
Tooling specifications and manuals are
found by selecting the products below .
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Hand Crimp Tool
0638191100
Hand Crimper -
DISTRIBUTION ONLY
0638111000
Insertion Tool
0011020003
Extraction Tool
0011030006
Crimp Quality Equipment
Molex Connector Part Number - 0002092103
Page 2 of 4
C:\TEMP\04192010\MOLE\0002092103.mht
20-Apr-2010
