This document was generated on 11/04/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Active
Description:
3.96mm (.156") Pitch KK Crimp Terminal Housing - Use With Trifurcon Terminals, 3
Circuits
Documents:
General
Product Family
Crimp Housings
Series
Product Name
KK
Physical
Circuits (maximum)
3
Color - Resin
Natural
Flammability
94V-2
Gender
Female
Glow-Wire Compliant
No
Material - Resin
Nylon
Number of Rows
1
Packaging Type
Bag
Panel Mount
No
Pitch - Mating Interface (in)
0.156 In
Pitch - Mating Interface (mm)
3.96 mm
Stackable
No
Temperature Range - Operating
0°C to +75°C
Electrical
CSA
LR19980
UL
E29179
Material Info
Old Part Number
6442-03-Z
Reference - Drawing Numbers
Product Specification
PS-40-02
Sales Drawing
SD-6442
Series image - Reference only
ELV and RoHS
Compliant
Not Reviewed
Not Reviewed
Need more information on product
environmental compliance?
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
6442 Series
Mates With
(.156") Pitch KK Crimp Terminal Housing -
Use With Trifurcon Terminals, 3 Circuits
Use With
This document was generated on 11/04/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
