參數資料
| 型號： | 0039301080 |
| 廠商： | MOLEX INC |
| 元件分類： | 電源輸入模塊 |
| 英文描述： | 8 CONTACT(S), MALE, POWER CONNECTOR, SOLDER |
| 封裝： | HALOGEN FREE AND ROHS COMPLIANT |
| 文件頁數： | 4/5頁 |
| 文件大小： | 159K |
| 代理商： | 0039301080 |
Plating min: Mating (in)
200
Plating min: Mating (m)
5.00
Plating min: Termination (in)
200
Plating min: Termination (m)
5.00
Polarized to Mating Part
Yes
Polarized to PCB
Yes
Shrouded
Fully
Stackable
No
Surface Mount Compatible (SMC)
No
Temperature Range - Operating
-40°C to +105°C
Termination Interface: Style
Through Hole
Electrical(Please review the Product Specification for specific details.)
Current - Maximum per Contact
13A
Voltage - Maximum
600V
Agency Certification
CSA
LR19980
TUV
R72081037
UL
E29179
Solder Process Data
Duration at Max. Process Temperature
(seconds)
5
Lead-free Process Capability
Wave Capable (TH only)
Max. Cycles at Max. Process
Temperature
1
Process Temperature max. C
240
Material Info
Old Part Number
5569-08A2
Reference - Drawing Numbers
Product Specification
PS-5556-001
Sales Drawing
SDA-5569-NA2*-*
Feedback
Privacy
Find us on:
Molex Connector Part Number - 0039301080
Page 4 of 5
C:\TEMP\04192010\MOLE\0039301080.mht
20-Apr-2010
