Physical
Circuits (Loaded)
20
Color - Resin
Natural
Contact Position
Top
Entry Angle
90° Angle
Flammability
94V-0
Mated Height (in)
0.197 In
Mated Height (mm)
5.00 mm
Material - Metal
Phosphor Bronze
Material - Plating Mating
Tin-Lead
Material - Plating Termination
Tin-Lead
Material - Resin
Polyester
Number of Rows
1
Orientation
Right Angle
PC Tail Length (in)
0.138 In
PC Tail Length (mm)
3.50 mm
PCB Locator
No
PCB Retention
None
Packaging Type
Tray
Pitch - Mating Interface (in)
0.049 In
Pitch - Mating Interface (mm)
1.25 mm
Plating min: Mating (in)
120
Plating min: Mating (m)
3
Plating min: Termination (in)
120
Plating min: Termination (m)
3
Polarized to PCB
No
Stackable
No
Surface Mount Compatible (SMC) No
Temperature Range - Operating
-20°C to +80°C
Termination Interface: Style
Through Hole
Wire/Cable Type
FFC/FPC
Electrical(Please review the Product Specification for specific details.)
Current - Maximum per Contact
1A
Voltage - Maximum
200V
Agency Certification
UL
E29179
Solder Process Data
Replacement RoHS Compliant
Part Number
0039532204
Molex Connector Part Number - 0039513203
Page 3 of 4
C:\TEMP\04192010\MOLE\0039513203.mht
20-Apr-2010
