TECHNICAL DATA SHEET
RPC-2.92
LAUNCHER JACK
FOR GLASSBEAD
02K526-800S3
Rosenberger Hochfrequenztechnik GmbH & Co. KG
Tel.: +49 8684 18-0
Page
P.O.Box 1260
D-84526 Tittmoning
Germany
Fax: +49 8684 18-499
www.rosenberger.de
email: info@rosenberger.de
2 / 2
RF_35/06.07/5.0
f(GHz)
Electrical data
Impedance
50
Ω
Frequency
DC to 40 GHz
Return loss 1)
≥ 23 dB, DC to 34 GHz
≥ 19 dB, 34 GHz to 40 GHz
Reflection coefficient (TDR) 2)
Step responce max.
± 15 mU
Insertion loss
≤ 0.04 x
dB
Insulation resistance
≥ 5 GΩ
Center contact resistance
≤ 3.0 mΩ
Outer contact resistance
≤ 2.0 mΩ
Test voltage
750 V rms
Working voltage
250 V rms
RF-leakage
≥ 100 dB up to 1 GHz
1)
measured including measuring adaptor 02K122-900S3
2)
measured with “time domain low-pass mode” including measuring adaptor 02K122-900S3
Mechanical data
Mating cycles
≥ 500
Center contact captivation
≥ 22 N
Coupling test torque
1.70 Nm
Recommended torque
0.80 Nm to 1.10 Nm
Environmental data
Temperature range
-40°C to +85°C
Thermal shock
MIL-STD-202, Method 107, Condition B
Corrosion
MIL-STD-202, Method 101, Condition B
Vibration
MIL-STD-202, Method 204, Condition D
Shock
MIL-STD-202, Method 213, Condition I
Moisture resistance
MIL-STD-202, Method 106
2002/95/EC (RoHS)
compliant
Tooling
Measuring adaptor
02K122-900S3
Suitable cables
N/A
Packing
Standard
100 pcs in blister
Weight
1.5 g/pce
Draft
Date
Approved
Date
Rev.
Engineering change number
Name
Date
Herbert Babinger
16/12/08
Armin Maiwaelder
09/09/09
a00
09-s475
Manuela Fuehrich
08/09/09
While the information has been carefully compiled to the best of our knowledge, nothing is intended as representation or warranty on
our part and no statement herein shall be construed as recommendation to infringe existing patents. In the effort to improve our
products, we reserve the right to make changes judged to be necessary.
