| 型號： | 02XSR-36S |
| 廠商： | J S T MFG CO LTD |
| 元件分類： | 電路板相疊連接器 |
| 英文描述： | 2 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, IDC, SOCKET |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 1/2頁 |
| 文件大小： | 115K |
| 代理商： | 02XSR-36S |
1
XSR CONNECTOR
0.6mm pitch/Disconnectable Insulation displacement connectors
Emboss Tape
3.0
0.29
1.45
This is the world's smallest 0.6mm pitch ID
connector for discrete wires.
This Wire to Board miniaturized connector
has a mounting height of 1.45mm and
depth of 3.0mm.
Space saving
Twin U-slot insulation displacement section
New strain relief structure
Suitable for thin wires
Applicable to automatic ID machines
Specifications –––––––––––––––––––
Current rating:
0.2A AC, DC
Voltage rating:
30V AC, DC
Temperature range: -25C to +85C
(including temperature rise in applying
electrical current)
Contact resistance: Initial value/30m
max.
After environmental testing/50m
max.
Insulation resistance:
100M
min.
Withstanding voltage:
200V AC/minute
Applicable wire: Conductor size/AWG #36
Conductor/7 strands,
tin-coated copper alloy
Insulation O.D./0.29mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Standards ––––––––––––––––––––––
0 Recognized E60389
1CertifiedLR20812
Note: 1. Tolerances are non-cumulative:
±0.05mm for all centers.
Note: 2. The dimensions above should serve as a guideline. Contact JST for details.
PC board layout (viewed from component side) and Assembly layout
