This document was generated on 11/17/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Active
Overview:
Description:
3.50mm (.138") Pitch MX150 Sealed Female Connector, Single Row, 6 Circuits,
Polarization A, without Connector Position Assurance, Black
Documents:
General
Product Family
Crimp Housings
Series
Comments
No Connector Position Assurance (CPA)
More Detailed Tech Information
Overview
MX150™ Sealed Connector System
Product Name
MX150
Physical
Circuits (maximum)
6
Circuits Detail
6
Color - Resin
Black
Color - Resin
Natural
Gender
Female
Glow-Wire Compliant
No
Keying to Mating Part
Yes
Lock to Mating Part
Yes
Material - Resin
Modified Polystyrene Alloy
Number of Rows
1
Packaging Type
Bag
Panel Mount
No
Pitch - Mating Interface (in)
0.138 In
Pitch - Mating Interface (mm)
3.50 mm
Polarized to Mating Part
Yes
Stackable
No
Temperature Range - Operating
-40°C to +125°C
Electrical
Current - Maximum
22A
Material Info
Reference - Drawing Numbers
Product Specification
PS-33471-000
Sales Drawing
SD-33471-061
Series image - Reference only
ELV and RoHS
Compliant
Not Reviewed
Not Reviewed
Need more information on product
environmental compliance?
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
33471 Series
Mates With
33481 Male Single Row Sealed Connector
Use With
33012 MX150 Female Terminal
This document was generated on 11/17/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
