This document was generated on 11/04/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Active
Overview:
Description:
Modular Jack, Vertical, 6/2
Documents:
General
Product Family
Modular Jacks/Plugs
Series
Comments
Flush Mount|Flangeless|2 PCB Thick
Component Type
PCB Jack
Overview
RJ-11
Performance Category
3
Power over Ethernet (PoE)
N/A
Product Name
RJ11
Physical
Color - Resin
Black
Durability (mating cycles max)
500
Flammability
94V-0
Inverted / Top Latch
N/A
Lightpipes/LEDs
None
Material - Metal
Phosphor Bronze
Material - Plating Mating
Gold
Material - Plating Termination
Tin
Material - Resin
Polyester
Orientation
Vertical (Top Entry)
PCB Retention
Yes
PCB Thickness Recommended (in)
0.062 In
PCB Thickness Recommended (mm)
1.60 mm
Packaging Type
Tray
Pitch - Mating Interface (in)
0.050 In
Pitch - Mating Interface (mm)
1.27 mm
Plating min: Mating (in)
50
Plating min: Mating (m)
1.25
Plating min: Termination (in)
100
Plating min: Termination (m)
2.5
Ports
1
Positions / Loaded Contacts
6/2
Surface Mount Compatible (SMC)
No
Temperature Range - Operating
-40°C to +80°C
Termination Interface: Style
Through Hole
Wire/Cable Type
N/A
Electrical
CSA
LR19980
Current - Maximum
1.5A
Shielded
No
UL
E107635
Voltage - Maximum
125V
Solder Process Data
Duration at Max. Process Temperature (seconds)
5
Series image - Reference only
ELV and RoHS
Compliant
Not Reviewed
Not Reviewed
Need more information on product
environmental compliance?
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
42410 Series
Mates With
FCC 68 Plugs
