Home
Crimp Housings
Datasheet
Part Number:
0430252400
Status:
Active
Overview:
Micro-Fit, 3.0
Description:
3.00mm (.118") Pitch Micro-Fit 3.0 Receptacle Housing, Dual Row, 24 Circuits
Documents: Note - Please disable browser pop-up blockers for documents on www.molex.com
Drawing (PDF)
Product Specification PS-43045 (PDF)
Series image - Reference only
EU RoHS
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Halogen-Free
For a multiple part number RoHS Certificate of
Compliance, click here
Molex Connector Part Number - 0430252400
Page 1 of 4
C:\TEMP\04192010\MOLE\0430252400.mht
20-Apr-2010
