This document was generated on 11/05/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Active
Description:
4.00mm (.157") Pitch Board-In Crimp Terminal 50098, 18-22 AWG, Reel, for 51036
Housing
Documents:
General
Product Family
Crimp Terminals
Series
Product Name
Board-In
Physical
Gender
Male
Material - Metal
Phosphor Bronze
Material - Plating Mating
Tin
Material - Plating Termination
Tin
Packaging Type
Reel
Plating min: Mating (in)
36
Plating min: Mating (m)
0.90
Plating min: Termination (in)
36
Plating min: Termination (m)
0.90
Termination Interface: Style
Crimp or Compression
Wire Insulation Diameter
1.80-2.60mm (.071-.102")
Wire Size AWG
18
Wire Size AWG
20
Wire Size AWG
22
Wire Size mm
N/A
Material Info
Reference - Drawing Numbers
Product Specification
PS-51036-002
Product Specification
PS-51036-003
Product Specification
RPS-51036-001
Product Specification
RPS-51036-002
Product Specification
RPS-51036-003
Sales Drawing
SD-50098-8*00
Series image - Reference only
ELV and RoHS
Compliant
Contains SVHC: No
Halogen-Free
Need more information on product
environmental compliance?
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
50098 Series
Use With
Application Tooling
| FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
FineAdjust
Applicator, 18-22
AWG
Japan
Description
Product #
Applicator for M211A
Bench Press, 18-22
AWG, for 50098
Crimp Terminal
Hand Crimp Tool,
18-22 AWG, for
50098 Crimp
Terminal
