1
2009 Littelfuse, Inc.
Specifications are subject to change without notice.
Axial Lead & Cartridge Fuses
3AB 1000VAC / DC High Voltage Fuse
508 Series
Please refer to www.littelfuse.com/series/508.html for current information.
508
Series
Agency
Agency File Number
Ampere Range
Recognised File: E10480
315mA - 500mA
508 Series Lead-Free 3AB Fuse
A 1000Vac/Vdc rated ceramic fuse with remarkable
interrupting rating in a compact 6.3 x 32mm package,
which is well suited for circuit protection in high energy
applications.
with Underwriter’s
Laboratories Standard
UL 248-14
and axial lead
Lead-free
rating of 10,000
Amperes
6.3 x 32mm
Agency Approvals
Features
Electrical Characteristics
Applications
% of Ampere
Rating
Ampere Rating
OpeningTime
100%
315mA - 500mA
135%
200%
Amp Code
Amp Rating
Voltage
Rating
Interrupting
Rating
Nominal Cold
Resistance
(mohms)
Nominal
Melting
I2t (A2 sec.)
Agency Approvals
.315
0.315
1000
10kA @ 1000Vac
10kA @ 1000Vdc
9200
0.071
x
.500
0.5
1000
3572
0.259
x
Electrical Characteristic
Used as supplementary protection in appliance or
components or internal circuits.
Description
Revised: March 29, 2011
