R.0.2P.991602-BEHRE
GHz TECHNOLOGY INC. RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE. GHz RECOMMENDS THAT BEFORE THE PRODUCT(S) DESCRIBED HEREIN ARE
WRITTEN INTO SPECIFICATIONS, OR USED IN CRITICAL APPLICATIONS, THAT THE PERFORMANCE CHARACTERISTICS BE VERIFIED BY CONTACTING THE FACTORY.
GHz Technology Inc. 3000 Oakmead Village Drive, Santa Clara, CA 95051-0808 Tel. 408 / 986-8031 Fax 408 / 986-8120
0809LD60P
60 WATT, 28V, 1 GHz
LDMOS FET
PRELIM I N A RY I S S U E
GENERAL DESCRIPTION
The 0809LD60P is a common source N-Channel enhancement mode lateral
MOSFET capable of providing 60 Watts of RF power from HF to 1 GHz. The
device is nitride passivated and utilizes gold metallization to ensure high
reliability and supreme ruggedness.
CASE OUTLINE
55QU
Common Source
ABSOLUTE MAXIMUM RATINGS
Power Dissipation
Device Dissipation @25
°C (P
d)
170 W
Thermal Resistance (
θ
JC)1.0°C/W
Voltage and Current
Drain-Source (VDSS)
65V
Gate-Source (VGS)
±20V
Temperatures
Storage Temperature
-65 to +200
°C
Operating Junction Temperature
+200
°C
ELECTRICAL CHARACTERISTICS @ 25
°°°°C
SYMBOL
CHARACTERISTICS
TEST CONDITIONS
MIN
TYP
MAX
UNITS
ΒV
dss
Drain-Source Breakdown
Vgs = 0V, Id = 2ma
65
70
V
Idss
Drain-Source Leakage Current
Vds = 28V, Vgs= 0V
1
A
Igss
Gate-Source Leakage Current
Vgs = 20V, Vds = 0V
1
A
Vgs(th)
Gate Threshold Voltage
Vds = 10V, Id = 100ma
2
4
5
V
Vds(on)
Drain-Source On Voltage
Vgs = 10V, Id = 3A
0.7
V
gFS
Forward Transconductance
Vds = 10V, Id = 3A
2.2
S
Ciss
Input Capacitance
Vds = 28V, Vgs = 0V, F = 1 MHz
90
pF
Crss
Reverse Transfer Capacitance
Vds = 28V, Vgs = 0V, F = 1 MHz
5
pF
Coss
Output Capacitance
Vds = 28V, Vgs = 0V, F = 1 MHz
60
pF
FUNCTIONAL CHARACTERISTICS @ 25
°°°°C
GPS
Common Source Power Gain
Vds = 28V, Idq = 0.3A,
F = 900MHz, Pout = 60W
14
dB
η
d
Drain Efficiency
Vds = 28V, Idq = 0.3A,
F = 900MHz, Pout = 60W
50
%
IMD3
Intermodulation Distortion,
3
rd Order
Vds = 28V, Idq = 0.3A,
Pout =60WPEP, F1 = 900 MHz,
F2 = 900.1 MHz
-30
dBc
Ψ
Load Mismatch
Vds = 28V, Idq = 0.3A,
F = 900MHz, Pout = 60W
10:1
