1612596-1 Product Details
1612596-1
T E I nternal N umber: 1 6 1 2 5 9 6 -1
PGA Sockets
Product Highlights:
l
Zero Insertion Force
l
754 Positions
l
PCB Mount Style = Surface Mount
l
Grid Size = 29x29
l
Grid Spacing = 1.27 x 1.27 mm
Quick Links
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
754 Position Lever Actuated ZIF Micro PGA Socket (PDF, Japanese)
Application Specifications:
l
Lever-Actuated Zero Insertion Force (ZIF) Micro Pin ... (PDF, Japanese)
Instruction Sheets:
l
Lever-Actuated Zero Insertion Force (ZIF) Micro Pin ... (PDF, English)
CAD Files:
l
None Available
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Insertion Force = Zero
l
Number of Positions = 754
l
PCB Mount Style = Surface Mount
l
Grid Size = 29x29
l
Grid Spacing (mm [in]) = 1.27 x 1.27 [.050 x .050]
l
Chip Compatibility = AMD Mobile K8, Clawhammer
l
Frame Style = Open
l
Heat Sink Attachment = Without
l
ZIF Actuator = Single Lever
l
Profile = Low
l
Cover Material = High Temperature Thermoplastic
l
Leg Style = Ball Grid Array (BGA)
Termination Related Features:
l
Socket Identifier = Socket 754
Body Related Features:
l
Assembly Process Feature = Pick and Place Cover, Plastic CAP
l
Actuator Handle Material = Stainless steel
l
Cover Color = Natural
l
Socket Overall Height (mm [in]) = 4 [0.157]
Contact Related Features:
l
Contact Style = Stamped + Formed
l
Contact Base Material = Copper Alloy
l
Contact Plating, Mating Area, Material = Gold (30)
l
Handle Type = Low Profile
Housing Related Features:
l
Housing Color = Black
l
Housing Material = High Temperature Thermoplastic
l
Housing Flammability Rating = UL 94V-0
l
Housing Material Temperature = High
Industry Standards:
l
RoHS/ELV Compliance = ELV compliant, 5 of 6 Compliant
l
Lead Free Solder Processes = Reflow solder capable to 245?C
Operation/Application:
l
Application = Production
Packaging Related Features:
l
Packaging Method = JEDEC Hard Tray
l
Packaging Quantity = 312 sockets/box
Other:
l
Brand = AMP
Corporate Information
Quick Links
Customer Support
Search by Keyword or Part #
