PAGE . 1
December 1,2010-REV.03
1N4148
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(TJ =25°C unless otherwise noted)
SWITCHING DIODES
VOLTAGE
100 Volts
POWER
500 mWatts
FEATURES
Fast switching Speed.
Electrically ldentical to Standerd JEDEC
High Conductance
Axial lead Package ldeally Suited for Automatic lnsertion.
In compliance with EU RoHS 2002/95/EC directives
MECHANICAL DATA
Case: Molded Glass DO-35
Terminals: Solderable per MIL-STD-750, Method 2026
Polarity: See Diagram Below
Approx. Weight: 0.13 grams
Mounting Position: Any
Ordering information: Suffix : “ -35 ” to order DO-35 Package
Packing information
B - 2K per Bulk box
T/R - 10K per 13" plastic Reel
T/B - 5K per horiz. tape & Ammo box
NOTE:
1. CJ at VR=0, f=1MHZ
2. From IF=10mA to IR=1mA, VR=6Volts, RL=100Ω
PARAMETER
SYMBOL
1N4148
UNITS
Peak Reverse Voltage
V
RM
100
V
Maximum Average Forward Current at T
A=25
O
C And f >50Hz
I
F(AV)
150
mA
Surge Forward Current at t < 1s and T
J= =25
O
C
I
FSM
500
mA
Power Dissipation at T
A= 25
O
C
P
TOT
500
mW
Maximum Forward Voltage at I
F =10mA
V
F
1.0
V
Maximum Leakage Current
at V
R=20V
at V
R=75V
at V
R=20V ,TJ= 150
O
C
I
R
25
5
50
nA
μ
A
μ
A
Maximum Capacitance at V
F =VR=0
C
J
4
pF
Maximum Reverse Recovery Time From
I
F =-IR =10mA to IRR=-1mA ,VR=6V RL=100 Ω
t
rr
4
ns
Typical Thermal Resistance
R
θ
JA
300
O
C / W
Junction Temperature and Storage Temperature Range
T
J,TS
-65 to +150
O
C
DO-35
UnitGinch(mm)
0.022(0.55)
0.018(0.45)
0.087(2.2)
0.06
3(1.6)
1.02(26.0)MIN.
0.141(3.6)
0.1
18(3.0)
1.02(26.0)MIN.
