29APR04
b
-
2:1
-
MAXMJ
MOD JACK - MJIM
-
8C8T, 1X4, INTEGRATED MAGNETICS
203258
I
SCHEMATIC NUMBER: H3D02
All Dimensions
in mm
www.ERNI.com
1
8
1
8
1
8
1
8
10.89 [.429]
3.20
±0.20
[.126
±.008]
13.80
[.543]
21.59
[.850]
MAX
59.09 [2.326]
53.34
±0.13 [2.100±.005]
3 x 13.97[.550] = (41.91 [1.650])
NOTE 1: SIDE SHIELD TABS IN FRONT 3.68mm (F2)
NOTE 2: REAR SHIELD TABS BETWEEN EACH PORT (T)
NOTE 3: PANEL GROUND FLANGES BOTH SIDES AND TOP (GF5)
LP
EMPFOHLENER FRONTPLATTEN AUSSCHNITT
RECOMMENDED PANEL CUTOUT
TOP OF PCB
0.38
±0.10
[.015
±.004]
60.19
±0.20 [2.370±.008]
14.89
[.586]
HOUSING: GLASS FILLED POLYESTER UL 94 V-0 BLACK
SHIELDING: Cu ALLOY, PLATING WITH Ni
ELECTRICAL CHARACTERISTICS
CONTACT RESISTANCE: 30 MILLIOHMS MAX
OPERATING TEMPERATURE: -40C TO 85C
TERMINAL FINISH: SnPb
CONTACT FINISH: Au, 0.8
m (30 in) OVER Ni
MECHANICAL CHARACTERISTICS
CONTACTS: PHOSPHOR BRONZE
DURABILITY: 1000 MATING CYCLES
MATERIALS AND FINISH
Scale
Designation
Tolerances
Consider
pr
otection
memo
fr
om
DIN
34
All rights reserved.
Only for information.
To insure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
Subject to modification without
prior notice.
Drawing will not be updated.
Date
Index
Information:
