205212-2 Product Details
Product View
205212-2
T E I nternal N umber: 2 0 5 2 1 2 -2
Standard Cable Connectors
Product Highlights:
l
Connector
l
Product Series = HDP-20 (Crimp Snap)
l
Number of Positions = 50
l
Plug
l
Without Contacts
Quick Links
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
AMPLIMITE SUBMINATURE D TYPE CONNEC TORS (PDF, English)
l
PERSONAL SYSTEMS PRODUCTS (PDF, English)
Product Specifications:
l
AMPLIMITE* HDP-20 Subminiature D Connector With F Cr... (PDF, English)
Application Specifications:
l
AMPLIMITE HDP-20 and Economy Crimp Snap Subminiature... (PDF, English)
Instruction Sheets:
l
AMPLIMITE High Density (HDP-20) Connectors with Crim... (PDF, English)
CAD Files: (CAD Format & Compression Information)
l
2D Drawing (DXF, Version F)
l
3D Model (IGES, Version F)
l
3D Model (STEP, Version F)
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Connector
l
Product Series = HDP-20 (Crimp Snap)
l
Number of Positions = 50
l
Gender = Plug
l
Wire Termination Type = Crimp Snap
l
Mating Connector Lock = With
l
Mating Connector Lock Type = Mounting Holes
l
Shell Size = 5
l
Shell Type = Front Metal Shell
l
Grounding Indents = Without
l
Grade = Standard
l
Color = Black
l
Shell Material = Steel
l
Comment = Plugs accept size 20 DF pin contacts.
Body Related Features:
l
Shell Plating = Tin-Lead
l
Insert Material = Thermoplastic
l
Insert Flammability Rating = UL 94V-0
Contact Related Features:
l
Contacts = Without
l
Contact Size = 20
Industry Standards:
l
RoHS/ELV Compliance = Not ELV/RoHS compliant
l
Lead Free Solder Processes = Not relevant for lead free process
Other:
l
Brand = AMP
