MOS FIELD EFFECT TRANSISTOR
2SK3056
SWITCHING
N-CHANNEL POWER MOS FET
INDUSTRIAL USE
DATA SHEET
Document No.
Date Published
Printed in Japan
D13095EJ1V0DS00 (1st edition)
March 1999 NS CP(K)
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
DESCRIPTION
This product is N-Channel MOS Field Effect Transistor
designed for high current switching applications.
FEATURES
Low On-State Resistance
R
DS(on)1
= 34 m
MAX. (V
GS
= 10 V, I
D
= 16 A)
R
DS(on)2
= 50 m
MAX. (V
GS
= 4.0 V, I
D
= 16 A)
Low C
iss
: C
iss
= 920 pF TYP.
Built-in Gate Protection Diode
ABSOLUTE MAXIMUM RATINGS (T
A
= 25 °C)
Drain to Source Voltage (V
GS
= 0 V)
V
DSS
60
V
Gate to Source Voltage (V
DS
= 0 V)
V
GSS(AC)
±20
V
Gate to Source Voltage (V
DS
= 0 V)
V
GSS(DC)
+20,
10
V
Drain Current (DC)
Drain Current (Pulse)
Note1
I
D(DC)
±32
A
I
D(pulse)
±100
A
Total Power Dissipation (T
C
= 25°C)
P
T
34
W
Total Power Dissipation (T
A
= 25°C)
P
T
1.5
W
Channel Temperature
T
ch
150
°C
Storage Temperature
Single Avalanche Current
Note2
Single Avalanche Energy
Note2
T
stg
–55 to +150
°C
I
AS
16
A
E
AS
25.6
mJ
Notes 1.
PW
≤
10
μ
s, Duty cycle
≤
1 %
2.
Starting Tch = 25 °C, R
G
= 25
,
V
GS
= 20 V
→
0 V
THERMAL RESISTANCE
Channel to Case
R
th(ch-C)
3.68
°C/W
Channel to Ambient
R
th(ch-A)
83.3
°C/W
ORDERING INFORMATION
PART NUMBER
PACKAGE
2SK3056
TO-220AB
2SK3056-S
TO-262
2SK3056-ZJ
TO-263
