TP2M4AL4FA8 Product Details
TP2M4AL4FA8
(3-1437568-4)
TE Internal Number: 3-1437568-4
Obsolete
Contact Product Information Center
Pushbutton Switches
Not reviewed for RoHS Compliance
Product Highlights:
l
Switch - Mechanical
l
Not Tactile
l
Double Pole - Double Throw Configuration (Pole-Throw)
l
Contact Rating = 0.4VA
l
Operating Function = Momentary
View all Features
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Quick Links
A dd to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Switch - Mechanical
l
Tactile = No
l
Configuration (Pole-Throw) = Double Pole - Double Throw
l
Mount Angle = Vertical
l
Termination Type = Printed Circuit
l
Actuator Style = Square
l
Frame Style = Square, Small
Electrical Characteristics:
l
Contact Rating = 0.4VA
Body Related Features:
l
Series
= TP-200
l
Mount Style = Through-Hole
l
Actuator Length (mm [in]) = 1.50 [0.059]
l
Actuator Profile = Extended
l
Actuator Color = Yellow
l
Case Material = Polyester
l
Actuator Material = Polyamide
Contact Related Features:
l
Contact Plating = Silver
Housing Related Features:
l
Process Sealed = No
l
Low Profile = No
Configuration Related Features:
l
Operating Function = Momentary
l
Ganged = No
l
ESD Grounding Terminal = Without
l
Actuator Force (g [oz]) = 200.00 [7.060]
l
Number of Actuators = Single
l
Illuminated = Yes
l
LED Color = Yellow
l
Dust Proof = No
l
Support Bracket = Without
l
Snap Action = Without
l
Frame Color = Dark Gray
Industry Standards:
l
RoHS/ELV Compliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Conditions for Usage:
l
Temperature Rating = Standard
Packaging Related Features:
l
Packaging Method = Loose Piece
Other:
l
Brand = Alcoswitch
