參數資料
| 型號： | 3-161390-7 |
| 廠商： | TYCO ELECTRONICS ALCOSWITCH |
| 元件分類： | 開關 |
| 英文描述： | SLIDE DIP SWITCH-7SWITCHES, SPST, LATCHED,THROUGH HOLE-STRAIGHT |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 2/2頁 |
| 文件大小： | 92K |
| 代理商： | 3-161390-7 |
3-161390-7
Active
DIP, RotaryDIP, SIP Switches and DIP Shunts - Standard
AlwaysEU RoHS/ELV Compliant
(
Statement ofCompliance
)
Product Highlights:
DIP Switch
PCB Mount Style = Thru Hole
Single Pole - Single Throw Configuration (Pole-Throw)
Actuator Style = Slide
Not Sealed
View all Features
|
FindSimilar Products
Previous
1
...
6
[7]
8
9
10
...
20
Next
QuickLinks
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Compare Products
Contact Us About This Product
Documentation& Additional Information
Product Drawings:
dip switch
(PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
List all Documents
Additional Information:
Product Line Information
RelatedProducts:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = DIP Switch
PCB Mount Style = Thru Hole
Configuration (Pole-Throw)
= Single Pole - Single Throw
Actuator Style
= Slide
Sealed = No
Number of Switches
= 7
Comment = Soldering in "off" position only
Body RelatedFeatures:
Centerline (mm [in]) = 2.54 [0.100]
Contact Related Features:
Auto-Insertable = No
Contact Material = Phosphor Bronze
Contact Mating Area Plating Material = Tin-Lead
Housing Related Features:
Housing Color = Gray
Housing Material = Polyester GF
Industry Standards:
RoHS/ELV Compliance
= RoHS compliant, ELV compliant
Lead Free Solder Processes
= Wave solder capable to 240C, Wave solder capable to 260C, Wave
solder capable to 265C
RoHS/ELV Compliance History = Always was RoHS compliant
Packaging RelatedFeatures:
Packaging Quantity = 75
Other:
Brand = Alcoswitch
