Document Number: 94190
Revision: 09-Sep-09
For technical questions, contact:
diodestech@vishay.com
www.vishay.com
1
Schottky Rectifier, 2 x 15 A
30CTQ...SPbF, 30CTQ...-1PbF
Vishay High Power Products
FEATURES
150 °C T
J
operation
Center tap configuration
Very low forward voltage drop
High frequency operation
High
purity,
encapsulation for enhanced mechanical
strength and moisture resistance
Guard ring for enhanced ruggedness and long
term reliability
Compliant to RoHS directive 2002/95/EC
Halogen-free according to IEC 61249-2-21 definition
AEC-Q101 qualified
high
temperature
epoxy
DESCRIPTION
This center tap Schottky rectifier has been optimized for very
low forward voltage drop, with moderate leakage. The
proprietary barrier technology allows for reliable operation up
to 150 °C junction temperature. Typical applications are in
switching power supplies, converters, freewheeling diodes,
and reverse battery protection.
PRODUCT SUMMARY
I
F(AV)
V
R
2 x 15 A
50 V/60 V
30CTQ...SPbF
Base
common
cathode
D
2
PAK
TO-262
30CTQ...-1PbF
Anode
Anode
Common
cathode
1
3
2
2
Base
common
cathode
Anode
Anode
Common
cathode
1
3
2
2
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
CHARACTERISTICS
VALUES
UNITS
I
F(AV)
V
RRM
I
FSM
Rectangular waveform
30
A
50/60
V
t
p
= 5 μs sine
1000
A
V
F
T
J
15 Apk, T
J
= 125 °C (per leg)
Range
0.56
V
- 55 to 150
°C
VOLTAGE RATINGS
PARAMETER
SYMBOL
30CTQ050SPbF
30CTQ050-1PbF
30CTQ060SPbF
30CTQ060-1PbF
UNITS
Maximum DC reverse voltage
V
R
50
60
V
Maximum working peak reverse voltage
V
RWM
ABSOLUTE MAXIMUM RATINGS
PARAMETER
SYMBOL
TEST CONDITIONS
VALUES
UNITS
Maximum average
forward current
See fig. 5
per device
I
F(AV)
50 % duty cycle at T
C
= 105 °C, rectangular waveform
30
A
per leg
15
Maximum peak one cycle non-repetitive
surge current per leg
See fig. 7
I
FSM
5 μs sine or 3 μs rect. pulse
Following any rated load
condition and with rated
V
RRM
applied
1000
10 ms sine or 6 ms rect. pulse
260
Non-repetitive avalanche energy per leg
E
AS
T
J
= 25 °C, I
AS
= 1.50 A, L = 11.5 mH
Current decaying linearly to zero in 1 μs
Frequency limited by T
J
maximum V
A
= 1.5 x V
R
typical
13
mJ
Repetitive avalanche current per leg
I
AR
1.50
A
* Pb containing terminations are not RoHS compliant, exemptions may apply
