TECHNICAL DATA SHEET
1.0/2.3
RIGHT ANGLE PLUG
SLIDE-ON, FOR 75
Ω CABLE
34S22A-340L5
Rosenberger Hochfrequenztechnik GmbH & Co. KG
Tel.: +49 8684 18-0
Page
P.O.Box 1260
D-84526 Tittmoning
Germany
Fax: +49 8684 18-499
www.rosenberger.de
email: info@rosenberger.de
2 / 2
RF_35/12.04/3.0
Electrical data
Impedance
50
Ω
Frequency
DC to 10 GHz
Insulation resistance
≥ 1x103 MΩ
Center contact resistance
≤ 4 mΩ
Outer contact resistance
≤ 2.5 mΩ
Test voltage
750 V rms
Working voltage
250 V rms
RF-leakage
≥ 90 dB up to 1 GHz
- Limitations are possible due to the used cable type -
Mechanical data
Mating cycles
≥ 500
Center contact captivation
≥ 10 N
Engaging and disengaging force
0.9 N to 10 N
Environmental data
Temperature range
-40°C to +85°C
Climatic class
IEC 60068-2-1 40/85/21
IEC 60068-2-2
IEC 60068-2-3
Vibration
IEC 60068-2-6
10 Hz to 2000 Hz, 100m/s
2002/95/EC (RoHS)
compliant
Tooling
Crimping tool
11W150-000
Crimp insert
11W150-104
Suitable cables
2YCY 0.4/2.5 (75
Ω cable)
Packing
Standard
100 pcs in bag
Weight
6.0 g/pce
Draft
Date
Approved
Date
Rev.
Engineering change number
Name
Date
Inge Mühlauer
21/09/04
Gramsamer J.
26.03.08
d00
07-0154
S_Kra.
26.03.08
While the information has been carefully compiled to the best of our knowledge, nothing is intended as representation or warranty on
our part and no statement herein shall be construed as recommendation to infringe existing patents. In the effort to improve our
products, we reserve the right to make changes judged to be necessary.
