Product Type Features:
Terminal Shape
= Ring Tongue
Receptacle Style
= Straight
Body Style
= SOLISTRAND
Barrel Type
= Closed Barrel
Wire/Cable Type
= Regular Wire
Insulation
= No
Insulation Support
= Non-Insulation Support
Stud Size = 3/8 [9.53]
Stud Diameter (mm [in])
= 9.53 [0.375]
Shape
= RING-048
Heavy Duty
= No
Material
= Copper
Finish
= Tin
Body Related Features:
Wire Range (mm [AWG])
= 8.002 [8]
Wire Range (CMA) = 13,100 – 20,800
Barrel I.D. Min. (mm [in]) = 4.37 [0.172]
Stock Thickness (mm [in]) = 1.30 [0.051]
Industry Standards:
Government/Industry Qualification = No
RoHS/ELV Compliance
= RoHS compliant, ELV compliant
Lead Free Solder Processes
= Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant
Packaging Related Features:
Packaging Method
= Loose Piece
Other:
Brand = AMP
Provide Website Feedback
|
Need Help
Page 2 of 2
