參數資料
| 型號： | 3652 |
| 元件分類： | 隔離放大器 |
| 英文描述： | Optically-Coupled Linear ISOLATION AMPLIFIERS |
| 中文描述： | 光耦合線性隔離放大器 |
| 文件頁數： | 6/13頁 |
| 文件大小： | 127K |
| 代理商： | 3652 |
2
3650/52
SPECIFICATIONS
At +25
°C and ±15VDC supply voltages, unless otherwise specified.
106
R
G1 + RG2 + RIN
R
G1 + RG2 + RIN + RO
25
90
±30
PRODUCT
3650MG, HG(1)
3650JG
3650KG
3652MG, HG(1)
3652JG
ISOLATION
Isolation Voltage
Rated Continuous, min
2000Vp or VDC
Tested Voltage, min, 10s Duration
5000Vp
Isolation Mode Rejection, G = 10
DC
140dB
60Hz, 5000
Source Unbalance
120dB
Leakage Current, 240V/60Hz
0.35
A, max
Isolation Impedance
Capacitance
1.8pF
Resistance
1012
GAIN
Gain Equation
for Current Sources
G1 = 106V/Amp
G1 = 1.0057 x 106V/Amp(2)
for Voltage Sources
GV1 =
V/V
Input Resistance, RIN, max
25
Buffer Output Impedance, RO
Not Applicable
Gain Equation Error, max(3)
1.5%
0.5%
1.5%(4)
0.5%(4)
Gain Nonlinearity
±0.05% typ ±0.2% max ±0.03% typ ±0.1% max ±0.02% typ ±0.05% max ±0.05% typ ±0.2% max ±0.05% typ ±0.1% max
Gain vs Temperature
300ppm/
°C
100ppm/
°C
50ppm/
°C
300ppm/
°C
200ppm/
°C
Gain vs Time
±0.05%/1000hrs
Frequency Response
Slew Rate
0.7V/
s min, 1.2V/s typ
±3dB Frequency
15kHz
Settling Time
to
±0.01%
400
s
to
±0.1%
200
s
INPUT STAGE(5)
Input Offset Voltage
at 25
°C, max(3)
±5mV
±1mV
±0.5mV
±5mV
±2mV
vs Temperature, max
±25V/°C
±10V/°C
±5V/°C
±50V/°C
±25V/°C
vs Supply
100
V/V
100
V/V
vs Time
50
V/1000hrs
100
V/1000hrs
Input Bias Current
at 25
°C
10nA typ, 40nA max
10pA typ, 50pA max
vs Temperature
0.3nA/
°C
Doubles Every +10
°C
vs Supply
0.2nA/V
1pA/V
Input Offset Current
10pA
vs Temperature
Effects Included
Doubles Every +10
°C
vs Supply
In Output Offset
1pA/V
Input Impedance
Differential
“RIN” = 25 max
1011
Common-Mode
109
1011
Input Noise
Voltage, 0.05Hz to 100Hz
4
Vp-p
8
Vp-p
10Hz to 10kHz
4
Vrms
5
Vrms
Input Voltage Range
Common-Mode, Linear Operation,
±(|V| –5)V
±(|V| –5)
w/o damage, at +, –
±V
at +I, –I
Not Applicable(6)
±300V for 10ms(7)
at +IR, –IR
Not Applicable(6)
±3000V for 10ms(7)
Differential, w/o damage, at +, –
±V
Differential, w/o damage, at +I, –I
Not Applicable
±600V for 10ms(7)
Differential, w/o damage,
at +IR, –IR
Not Applicable
±6000V for 10ms(7)
Common-Mode Rejection, 60Hz
90dB at 60Hz, 5k
Imbalance
80dB at 60Hz, 5k
Imbalance
Power Supply (Input Stage Only)
Voltage (at “+V” and “–V”)
±8V to ±18V
Current
Quiescent
±1.2mA(8)
±3mA(8)
with
±10V Output(7)
+6.5mA or –6.5mA, typ
+8.5mA or –8.5mA, typ
+12mA or –12mA, max
+16mA, or –16mA, max
