4-1825010-0
Active
Slide Switches
AlwaysEU RoHS/ELV Compliant
(
Statement ofCompliance
)
Product Highlights:
Number of Positions = 6
Six Pole - Double Throw Configuration (Pole-Throw)
Actuator Style = Extended, Side
Actuator Color = Natural
ASE/F Series
View all Features
|
FindSimilar Products
Previous
1
...
16
17
18
19
[20]
Next
QuickLinks
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Compare Products
Contact Us About This Product
Documentation& Additional Information
Product Drawings:
SLIDE SWITCH ASE/ASF,AUTO-INSERTABLE, THRU-HOLE AND...
(PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
List all Documents
Additional Information:
Product Line Information
RelatedProducts:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Number of Positions
= 6
Configuration (Pole-Throw) = Six Pole - Double Throw
Actuator Style = Extended, Side
Mount Angle = Vertical
Grade = Telecom
Termination Type = PC
Electrical Characteristics:
Contact Rating = 300mA @ 115 VDC
Body RelatedFeatures:
Actuator Color = Natural
Series = ASE/F
Mount Style = Through-Hole
SwitchStyle = Auto-insertable
PCB Tail Length (mm [in]) = 4.06 [0.160]
Actuator Material = Polyester
Contact Related Features:
Contact Plating = Gold
Contact Material = Copper Alloy
Configuration Related Features:
Terminal Configuration = Standard
Number of Actuators = Single
Industry Standards:
RoHS/ELV Compliance
= RoHS compliant, ELV compliant
Lead Free Solder Processes
= Wave solder capable to 240C, Wave solder capable to 260C, Wave
solder capable to 265C
RoHS/ELV Compliance History = Always was RoHS compliant
Identification Markng:
Stamped Marking = With
Other:
Brand = Tyco Electronics
