參數資料
| 型號： | 400DMQ045 |
| 廠商： | International Rectifier |
| 英文描述： | SCHOTTKY RECTIFIER |
| 中文描述： | 肖特基整流器 |
| 文件頁數： | 1/5頁 |
| 文件大小： | 67K |
| 代理商： | 400DMQ045 |
I
F(AV)
Rectangular
400
A
waveform
V
RRM
range
35 to 45
V
I
FSM
@ tp = 5 s sine
29,000
A
V
F
@200Apk,T
J
=125°C
0.52
V
(per leg)
T
J
range
-55to150
°C
Characteristics
400DMQ... Units
Major Ratings and Characteristics
Description/ Features
The 400DMQ high current, Schottky rectifier doubler module
series has been optimized for very low forward voltage drop,
with moderate leakage. The proprietary barrier technology
allows for reliable operation up to 150 °C junction temperature.
Typical applications are in switching power supplies, convert-
ers, free-wheeling diodes, welding, and reverse battery
protection.
150 °C T
J
operation
High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
Very low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term
reliability
SCHOTTKY RECTIFIER
400 Amp
400DMQ... SERIES
1
Bulletin PD-20736 rev. B 10/02
TO-244AB
isolated doubler
Modified JEDEC
Outline TO-244AB Isolated
Dimensions in millimeters and (inches)
1
2
3
www.irf.com
