120 & 240 Vac Models
0-5 Vdc Phase Control
Models CPV120 and CPV240 auxiliary
function modules provide control of the
phased turn-on of a solid state relay, in
response to the application of a 0-5 Vdc
control signal. They must be used with
SERIES CPV
Rev. 101607
PAGE 1 OF 3
Crydom Series 1 (-10) random turn-on
solid state relays. Consult factory about
use with 480 Vac loads.
For a com-
plete set (control module and solid state
relay) order 10CPV120, 25CPV120, etc.
Manufactured in Crydom's ISO 9001
Certified facility for optimum product
performance and reliability.
MODEL NUMBERS
120 Vac
10CPV120
25CPV120
40CPV120
240 Vac
10CPV240
25CPV240
50CPV240
75CPV240
90CPV240
RELAY OUTPUT SPECIFICATIONS 1
Operating Voltage Range (47-63 Hz) [Vrms]
90-140 (120 Vac Models)
180-280 (240 Vac Models)
Load Current Range
[Arms]
.04-10
.04-25
.04-50
.04-75
.04-90
Transient Overvoltage [Vpk]
400 (120 Vac models)
600 (240 Vac models)
Max. Surge Current, (16.6ms) [Apk]
120
250
625
1000
1200
Max. On-State Voltage Drop @ Rated Current [Vpk]
1.6
Thermal Resistance Junction to Case [R qJC ] C/W
1.48
1.02
0.63
0.31
0.28
Maximum I 2 t for Fusing, (8.3 msec.) [A 2 sec]
60
260
1620
4150
6000
Max. Off-State Leakage Current @ Rated Voltage [mArms]
10.0
Min. Off-State dv/dt @ Max. Rated Voltage [V/sec]
500
Max. Turn-On Time [msec]
0.02
Max. Turn-Off Time
1/
2 cycle
1/
2 cycle
1/
2 cycle
1/
2 cycle
1/
2 cycle
Power Factor (Min.) with Max. Load
0.5
CONTROL MODULE INPUT SPECIFICATIONS
DC CONTROL
Logic Supply Range (Terminal 3A)
3.5-10Vdc
Typical Supply Current
1.6mA @ 5Vdc
Control Voltage Range (Terminal 3B)
0-5 Vdc
Nominal Control Input Impedance
1500Ohms
Min. Turn-Off Voltage
1.0
CONTROL MODULE OUTPUT (Terminal 4B - Input to Relay)
Max. Off-State Operating Voltage
36 Vdc
Max. Load Current (Sink)
3.0 mA
Max. On-State Voltage @ 3mA
0.5 Vdc
Max. Off-State Leakage @ 10Vdc
1.0 Adc
GENERAL NOTES
All parameters at 25°C unless otherwise specified.
Off-State dv/dt test method per
EIA/NARM standard RS-443,
paragraph 13.11.1
Heat sinking required (Relay Only),
see Series 1 data sheet.
2007 CRYDOM Inc., Specifications subject to change without notice.
Series
CPV
Phase Control Modules
For recommended applications and more information contact:
USA: Sales Support (877) 502-5500 Tech Support (877) 702-7700 FAX (619) 710-8540
Crydom Inc., 2320 Paseo de las Americas, Ste. 201, San Diego, CA 92154
Email: sales@crydom.com WEB SITE: http://www.crydom.com
UK: +44 (0)1202 606030 FAX +44 (0)1202 606035 Crydom SSR Ltd., Arena Business Centre,
Holyrood Close, Poole, Dorset BH17 7FJ, Email: intsales@crydom.com.
GERMANY: +49 (0)180 3000 506
