42752-1 Product Details
Product View
42752-1
T E I nternal N umber: 4 2 7 5 2 -1
Ring and Spade Tongue Terminals
Product Highlights:
l
Terminal Shape = Ring Tongue
l
Receptacle Style = Straight
l
Barrel Type = Open Barrel
l
Wire/Cable Type = Regular Wire
l
Wire Range = 1.25-2.50 [16-13.5] mm [AWG]
Quick Links
Documentation & Additional Information
Product Drawings:
l
# ring (PDF, English)
Catalog Pages/Data Sheets:
l
MACHINE APPLIED TERMINATIONS, OPEN BARREL (PDF, English)
Product Specifications:
l
Terminal, AMPLIVAR, Ring, Crimping (PDF, English)
l
Terminal, Ring, Extruded, Crimping (PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files: (CAD Format & Compression Information)
l
2D Drawing (DXF, Version K)
l
3D Model (IGES, Version K)
l
3D Model (STEP, Version K)
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Terminal Shape = Ring Tongue
l
Receptacle Style = Straight
l
Barrel Type = Open Barrel
l
Wire/Cable Type = Regular Wire
l
Insulation = No
l
Insulation Support = Insulation Support
l
Insulation Diameter (mm [in]) = 3.00-4.60 [.118-.181]
l
Stud Size = None
l
Stud Diameter (mm [in]) = 8.20 [0.323]
l
Shape = RING-001
l
Heavy Duty = No
l
Material = Brass
l
Finish = None
Body Related Features:
l
Wire Range (mm [AWG]) = 1.25-2.50 [16-13.5]
l
Stock Thickness (mm [in]) = 0.76 [0.030]
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV Compliance = RoHS compliant, ELV compliant
l
Lead Free Solder Processes = Not relevant for lead free process
l
RoHS/ELV Compliance History = Always was RoHS compliant
Packaging Related Features:
l
Packaging Method = Strip
Other:
l
Brand = AMP
