435802-3
Active
DIP, RotaryDIP, SIP Switches and DIP Shunts - Standard
5 of6 EU RoHS/ELV Compliant
(
Find RoHS CompliantAlternates
/
Statement ofCompliance
)
Product Highlights:
DIP Switch
PCB Mount Style = Thru Hole
Single Pole - Single Throw Configuration (Pole-Throw)
Actuator Style = Piano (Side Actuated)
Not Sealed
View all Features
|
FindSimilar Products
Previous
1
...
11
12
13
[14]
15
...
20
Next
QuickLinks
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Compare Products
Contact Us About This Product
Documentation& Additional Information
Product Drawings:
SWITCH ASSY, DIP, TYPE ''C'', 7000 SERIES, SPST, SID...
(PDF, English)
Catalog Pages/Data Sheets:
MULTI-USER SYSTEMS
(PDF, English)
ALCOSWITCH PRODUCTS
(PDF, English)
PERSONAL SYSTEMS PRODUCTS
(PDF, English)
Product Specifications:
None Available
Application Specifications:
Dual In-Line Package (DIP) Programming Switches (700...
(PDF, English)
Instruction Sheets:
Dual In-Line Package (DIP) Programming Switches (700...
(PDF, English)
CAD Files:
(
CAD Format & Compression Information
)
2D Drawing
(DXF, Version AK)
3D Model
(IGES, Version AK)
3D Model
(STEP, Version AK)
List all Documents
Additional Information:
Product Line Information
Additional Product Images:
Recommended PC Board Hole Pattern
RelatedProducts:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = DIP Switch
PCB Mount Style = Thru Hole
Configuration (Pole-Throw)
= Single Pole - Single Throw
Actuator Style
= Piano (Side Actuated)
Sealed = No
Number of Switches
= 4
Comment = All switches are bottom sealed.
TerminationRelated Features:
Termination (Solder) Post Length (mm [in]) = 3.56 [0.140]
Body RelatedFeatures:
Series = 7000
Centerline (mm [in]) = 2.54 [0.100]
Contact Related Features:
Auto-Insertable = No
Contact Material = Copper Alloy
Contact Mating Area Plating Material = Gold (30) over Nickel (50)
Housing Related Features:
Low Profile = Yes
Housing Color = Black
Housing Material = Polyester GF
Housing Flammability Rating = UL 94V-0
Industry Standards:
RoHS/ELV Compliance
= ELV compliant, 5 of 6 Compliant
Lead Free Solder Processes
= Wave solder capable to 240C, Wave solder capable to 260C, Wave
solder capable to 265C
Packaging RelatedFeatures:
Packaging Quantity = 25
Other:
Brand = Alcoswitch
