YOUDA INTEGRATED CIRCUIT
YD4558
ABSOLUTE MAXIMUM RATINGS
(Tamb=25℃)
PARAMETER
SYMBOL
VALUE
UNIT
Supply Voltage
Vcc
±18
V
Differential Input Voltage
VI(DIFF)
±30
V
DIP8
500
Power
Dissipation
SOP8
PD
250
mW
D terminal Output Voltage
VI
±15
V
Operating Temperature
Topr
-20～+75
℃
Storage Temperature
Tstg
-40～+125
℃
ELECTRICAL CHARACTERISTICS
(Vcc=15V, Vee=-15V, Tamb=25℃,Unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITION
MIN
TYP
MAX
UNIT
Supply Current
ICC
4.0
6.0
mA
Input Offset Voltage
VIO
RS＜10kΩ
0.5
6
mV
Input Offset Current
IIO
5
200
nA
Input Bias Current
IBIAS
25
500
nA
Large Signal Voltage Gain
Avo
Vo(p-p)=10V,
RL＜2kΩ
86
100
dB
Common Mode Input
Voltage Range
VICM
±12
±14
V
Common Mode Rejection
Ratio
KCMR
RS＜10kΩ
70
90
dB
Supply Voltage Rejection Ratio
KSVR
RS＜10kΩ
76.5
90
dB
Output Voltage Swing
Vo(p-p)
RS＞10kΩ
±12
±14
V
Slew Rate
SR
Vi=20mV, RL＞2kΩ,
CL＜100p
1.0
V/μs
Rise Time
TRIS
Vi=20mV, RL＞2kΩ,
CL＜100p
0.3
μs
Overshoot
OS
Vi=20mV, RL＞2kΩ,
CL＜100p
15
%
WuXi YouDa Electronics Co., Ltd
2 of 3
Website: www.e-youda.com
