Characteristics and dimensions of terminals
Part number
46700.201.185
Specification
AFK
Material
CuSn
Surface / Colour
frSn 1
Form
Single form
Assembly
X
Packing unit / piece
3000
Section area (mm2)
0.20-0.35
Type of lead
FLR
Insulation diameter (mm)
1.1 - 1.5
Tab thickness (mm)
0.80
Tab width (mm)
2.80
Nominal size
2.8x0.8-0.35
Material thickness (mm)
0.32
Steel spring
X
a1
5.60
a2
2.50
l1
18.80
Note: The drawing only gives an overview of the geometry of the part. The crimp area is shown as
supplied in strip form. A technical drawing is available on request.
Packing Units (per 3000 pieces)
CW
http://www.ghw-online.com/cgi-bin/teilseite.cgi?lang=E&t=46700&w=201&o=185 [3/6/2002 11:09:16 AM]
