353-10-1xx-00-001
353-90-1xx-00-001
453-10-2xx-00-001
453-90-2xx-00-001
Pin header strip, wrapost, single
row / double row. Solder tail see
page 44
Single row, availability from: 1 to
64 contacts
Standard number of contacts 5,
6, 8, 10, 14, 16, 20, 21, 25, 30,
32, 48, 56, 60 and 64
Double row, availability from 4 to
72 contacts
Standard number of contacts 40,
44, 56, 64 and 72
360-10-1xx-00-001
360-90-1xx-00-001
363-10-1xx-00-001
363-90-1xx-00-001
460-10-2xx-00-001
460-90-2xx-00-001
463-10-2xx-00-001
463-90-2xx-00-001
Slotted head strip, solder tail or
wrapost, single row / double row
Single row, availability from: 1 to
64 contacts
Standard number of contacts 5,
6, 8, 10, 14, 16, 20, 21, 25, 30,
32, 48, 56, 60 and 64
Double row, availability from 4 to
72 contacts
Standard number of contacts 40,
44, 56, 64 and 72
370-10-1xx-00-001
370-90-1xx-00-001
373-10-1xx-00-001
373-90-1xx-00-001
470-10-2xx-00-001
470-90-2xx-00-001
473-10-2xx-00-001
473-90-2xx-00-001
Turret head strip, solder tail or
wrapost, single row / double row
Single row, availability from: 1 to
64 contacts
Standard number of contacts 5,
6, 8, 10, 14, 16, 20, 21, 25, 30,
32, 48, 56, 60 and 64
Double row, availability from 4 to
72 contacts
Standard number of contacts 40,
44, 56, 64 and 72
380-10-1xx-00-001
380-90-1xx-00-001
383-10-1xx-00-001
383-90-1xx-00-001
480-10-2xx-00-001
480-90-2xx-00-001
483-10-2xx-00-001
483-90-2xx-00-001
Solder cup strip, solder tail or
wrapost, single row / double row
Single row, availability from: 1 to
64 contacts
Standard number of contacts 5,
6, 8, 10, 14, 16, 20, 21, 25, 30,
32, 48, 56, 60 and 64
Double row, availability from 4 to
72 contacts
Standard number of contacts 40,
44, 56, 64 and 72
74
Series 353–383 / 453– 483
PCB Header Strips
Single row / double row
Wire-wrap / solder tail
Headers
With pin / slotted / turret / solder cup head
Solder tail or wrapost
Solder tail pin
0.53 mm
Wrapost termination s
s 0.63 square
Ordering information
Replace xx with the number of poles. e.g. 460-10-2xx-00-001
for a double row version with 8 pins per row becomes:
460-10-216-00-001
Platings
Sleeve
Clip
Pin
10
0.25
m Au
90
5
m Sn Pb
B
Products not available from stock. Please consult PRECI-DIP.
B
