Electronic Components | Segments | Who We Are
Searc h
4PCV-25-005 Product Details
Product Photo
4PCV-25-005
(4-1437649-2)
T E I nternal N umber: 4 -1 4 3 7 6 4 9 -2
Barrier Strips, Barrier Strip Sockets
Product Highlights:
l
Barrier Strip
l
Barrier Style = Single Row, Tri-Barrier
l
Block Style = Open Bottom with Standoffs
l
8.26 mm Centerline
l
Vertical Mount Angle
Quick Links
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Barrier Strip
l
Mount Angle = Vertical
l
Number of Positions = 25
l
CSA File No. = LR30811
l
UL Recognized = File No. E54800
l
Screw Material = Steel
l
Mounting Ears = Without
l
Comment = Do not order Screw and Captive Clamp in combination
with other top hardware.; Other options available upon request,
consult our Product Information Center.
Mechanical Attachment:
l
Screw Plating = Bright Zinc/Chrome
l
Mounting Style = Direct (All Positions Filled)
Electrical Characteristics:
l
Top Hardware = Wire Clamp Combo Head
l
Number of Levels = Single
l
End Barriers = Without
l
Bracket = Without
l
Screw Head Type = Phil-Slot
l
Current Rating, Max. (Amps.) = UL: 20A, CSA: 25A
l
Mounting Insert = Without
Body Related Features:
l
Barrier Style = Single Row, Tri-Barrier
l
Block Style = Open Bottom with Standoffs
l
Centerline (in [mm]) = 0.325 [8.26]
l
Number of Rows = Single
l
Terminal Style = Printed Circuit Pin 5.08 [.200]
l
Wire Range (mm [AWG]) = 0.30-3.00 [22-12]
Contact Related Features:
l
Mounting Options = None
l
Mounting Bushing = With
Industry Standards:
l
RoHS/ELV Compliance = Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes = Not reviewed for lead free solder
process
Other:
l
Brand = Buchanan
