Sockets
SIP Sockets
5-1437535-4
(Tyco Electronics P/N: 5-1437535-4)
Document links for this part cannot be displayed. Your browser does not support inline frames or
is currently configured not to display inline frames. Inline frames are supported in both Internet
Explorer 5 and Netscape 6, as well as all later versions of these browsers.
Related Part Information
General Information
eCommerce
Related Part Information
Searchable Features:
Brand:
AMP
RoHS/ELV Compliance:
RoHS compliant,
ELV compliant
Lead Free Solder
Process:
Reflow solder
capable to 245°C
No. of Positions:
20
Contact Style:
Stamped + Formed
Leg Style:
Standard
Contact Material:
Beryllium Copper
Contact Mating Area
Plating:
Gold (10)
Termination Post
Length (mm [in]):
3.18 [0.125]
Sleeve Material:
Brass
Other Properties:
RoHS/ELV
Compliance History:
Always was
compliant
Sleeve Plating:
Gold
Housing Material:
Thermoplastic
Polyester
Housing Flammability
Rating:
UL 94V-0
Breakaway Header:
Yes
