Sockets
PGA Sockets
5-1565228-1
(Tyco Electronics P/N: 5-1565228-1)
Document links for this part cannot be displayed. Your browser does not support inline frames or
is currently configured not to display inline frames. Inline frames are supported in both Internet
Explorer 5 and Netscape 6, as well as all later versions of these browsers.
Related Part Information
General Information
eCommerce
Related Part Information
Searchable Features:
Brand:
AMP
RoHS/ELV
Compliance:
ELV compliant
Lead Free
Solder
Process:
Not suitable for lead free processing
Insertion
Force:
Zero
No. of
Positions:
479
PCB Mount
Style:
Surface Mount
Grid Size:
26x26
Grid Spacing
(mm [in]):
1.27 x 1.27 [.050 x .050]
Chip
Compatibility:
Intel Pentium 3 MOBILE
(mPGA478A pattern), Intel
Pentium 4 (mPGA478B pattern),
Intel Pentium 4 Processor -M
MOBILE (mPGA478B pattern), Intel
Pentium M MOBILE (mPGA478C
pattern)
Application:
Production
Other Properties:
RoHS/ELV
Compliance
History:
Always was
compliant
Housing Color:
Black
Housing
Material:
High
Temperature
Thermoplastic
Housing
Flammability
Rating:
UL 94V-0
Cover Material:
High
Temperature
Thermoplastic
Cover Color:
Black
Socket Overall
Height (mm
[in]):
3 [0.118]
Leg Style:
Ball Grid Array
(BGA)
Housing
Material
Temperature:
High
