5-210797-3 Product Details
5-210797-3
T E I nternal N umber: 5 -2 1 0 7 9 7 -3
PGA Sockets
Product Highlights:
l
Ultra Low Insertion Force
l
145 Positions
l
PCB Mount Style = Through Hole
l
Grid Size = 15x15
l
Grid Spacing = Standard: 2.54 x 2.54 mm
Quick Links
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Insertion Force = Ultra Low
l
Number of Positions = 145
l
PCB Mount Style = Through Hole
l
Grid Size = 15x15
l
Grid Spacing (mm [in]) = Standard: 2.54 x 2.54 [.100 x .100]
l
Chip Compatibility = Other
l
Frame Style = Open
l
Sleeve Material = Phosphor Bronze
l
Heat Sink Attachment = Without
l
Profile = Standard
l
Leg Style = ACTION PIN
Termination Related Features:
l
Termination Post Length (mm [in]) = 4.04 [0.159]
l
Socket Identifier = None
l
Solder Tail Contact Plating = Tin-Lead over Nickel
Body Related Features:
l
Assembly Process Feature = None
l
Socket Overall Height (mm [in]) = 4.46 [0.176]
Contact Related Features:
l
Contact Style = Stamped + Formed
l
Contact Base Material = Beryllium Copper
l
Contact Plating, Mating Area, Material = Gold (30)
l
Sleeve Plating = Tin-Lead (120) over nickel
Housing Related Features:
l
Housing Color = Black
l
Housing Material = Thermoplastic - GF
l
Housing Flammability Rating = UL 94V-0
l
Housing Material Temperature = High
Industry Standards:
l
RoHS/ELV Compliance = Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes = Not reviewed for lead free solder
process
Operation/Application:
l
Application = Production
Packaging Related Features:
l
Packaging Method = Tube
Other:
l
Brand = AMP
