5-348000-8 Product Details
No Im age Available
5-348000-8
T E I nternal N umber: 5 -3 4 8 0 0 0 -8
SIP Sockets
Product Highlights:
l
Number of Positions = 58
l
Contact Style = Screw Machine
l
Leg Style = Standard
l
Beryllium Copper Contact Base Material
l
Gold (20) Contact Mating Area Plating Material
Quick Links
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Number of Positions = 58
l
Leg Style = Standard
l
Sleeve Material = Gold (10)
l
Breakaway Header = Yes
Termination Related Features:
l
Termination Post Length (mm [in]) = 2.84 [0.112]
Body Related Features:
l
Centerline (mm [in]) = 2.54 [0.100]
Contact Related Features:
l
Contact Style = Screw Machine
l
Contact Base Material = Beryllium Copper
l
Contact Mating Area Plating Material = Gold (20)
Housing Related Features:
l
Housing Material = Thermoplastic Polyester
Industry Standards:
l
RoHS/ELV Compliance = Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes = Not reviewed for lead free solder
process
Other:
l
Brand = AMP
