Telephone
+44 (0)1229 582430
Fax: + 44 (0)1229 585155
email: sales@marl.co.uk
website: www.marl.co.uk
website: www.marl-leds.com
Making Light Work For
You!
Making Light
Work For You!
Making
Light Work For You! Making Light
Work For You!
Making Light
PART NUMBER
COLOUR
LENS
VOLTAGE
DC
Vf@20mA
CURRENT
DC
lopr
LUMINOUS
INTENSITY
lv@20mA
WAVE
LENGTH
λ
p
VIEWING
ANGLE
OPERATING
TEMP
Topr
STORAGE
TEMP
Tstg
S T A NDA R D INT ENS IT Y
528-501-21
Red
12
20
2750
660
528-521-21
Yellow
12
20
4500
590
528-532-21
Green
12
20
6000
525
528-930-21
Blue
12
20
2000
470
528-997-21
White
Coloured Diffused
12
20
3000
Wide
-40~ + 60
-50~ + 100
528-501-22
Red
24
20
2750
660
528-521-22
Yellow
24
20
4500
590
528-532-22
Green
24
20
6000
525
528-930-22
Blue
24
20
2000
470
528-997-22
White
24
20
3000
UNITS
Vdc
mA
mcd
nm
°C
°C
HIGH INTENSITY
PR OFES S IONA L LED INDICA T OR S - 13m m M ounting
MLQ = 10
5 2 8
SERIES
Dimensions in mm(Typical)
Scale 1:1
LEDs
LEDs
R obust stainless
steel housing
Low profile
styling
Flying lead
term inations
available
S ealed to IP67
= Typical emssion colour: x= 0.31, y= 0.32. Colour temperature 8000K. Intensities (Iv) and colour shades of white (x,y co-ordinates) may vary between LEDs within a batch.
Please note - This product is also available at 28 and 48Vdc, 110 and 230Vac. Please contact our Sales department for further details.
Ordering Information & Typical Technical Characteristics (Ta = 25°C)
Mean Time Between Failure = 100,000 Hours. Luminous intensity figures refer to the unmodified discrete LED.
IS O 9001: 1994 A PPR OV ED
Anode termnation indicated by + on moulded
header.
