參數資料
| 型號： | 53252-PC-H |
| 廠商： | MICROPAC INDUSTRIES INC |
| 元件分類： | 繼電器，輸入/輸出模塊 |
| 英文描述： | DUAL TRANSISTOR OUTPUT SOLID STATE RELAY, 1000 V ISOLATION-MAX |
| 封裝： | HERMETIC SEALED, CERAMIC, DIP-8 |
| 文件頁數： | 1/6頁 |
| 文件大?。?/td> | 142K |
| 代理商： | 53252-PC-H |
Micropac Industries cannot assume any responsibility for any circuits shown or represent that they are free from patent infringement.
Micropac reserves the right to make changes at any time in order to improve design and to supply the best product possible.
MICROPAC INDUSTRIES, INC. MICROCIRCUITS DIVISION
905 E. Walnut St., Garland, TX 75040 (972) 272-3571 Fax (972) 494-2281
www.micropac.com
E-MAIL: hybridsales@micropac.com
8/30/02
Pg. 1 of 6
53252
90V - 0.8A DUAL POWER
MOSFET OPTOCOUPLERS
Mii
MICROCIRCUITS DIVISION
Features:
8-Pin Dual-In-Line Hermetic Package
Performance over –55°C to +125°C
Compact Isolation Solid State Switches
Continuous Output Current: 0.8 A
(1)
Optically Coupled between Input and Output
Isolation Tested to 1000 VDC
High Level of Transient Immunity
3 A Output Surge Current
Shock and Vibration Resistant
MIL-PRF-38534 screening optional
Applications:
Military/High Reliability Systems
Standard 28 VDC and 48 VDC Load Driver
Aircraft Controls
Electromechanical and Solid State Relay
Replacement
I/O Modules
Switching Heaters
DESCRIPTION
The 53252 is two power MOSFET optocouplers in a single 8-pin dual-in-line package suitable for applications
where two independent switches are required. The popular hermetic eight-pin dual-in-line ceramic package
combined with 1000 VDC isolation between input and output and between two isolated relays, makes this device
ideal for solid-state relay applications. Performance is specified over the full military temperature range. This device
is available in a variety of quality levels from COTS to class K including any custom screening requirements. The
basic data sheet part is environmentally screened to H level in accordance with Table C-IX of MIL-PRF-38534.
Lead options support both through-hole and surface-mount assembly. Gold plated leads are standard, but other
lead finishes per MIL-PRF-38534 are also available.
Functionally, the device operates as two SPST, normally open (2 Form A) solid-state relays. Each relay is actuated
by an input current, which can be driven from a standard TTL device. The input current biases a light emitting diode
that is optically coupled to an integrated photovoltaic diode array. The photovoltaic diode array energizes control
circuitry that operates the output MOSFET.
