ProductNumber:550-90-499-22-135012
499-22-135
22X22
Description:
PGA Header
Solder Tail Pin Header
Through Hole
PlatingCode:
90
ShellPlating:
200 μ" Tin/Lead(93/7) over 100 μ"
Nickel
#
Of
Pins
Mill-Max
Part
Number
RoHS
Compliant
499
550-90-499-22-135012
LOOSEPIN:
Pin Used: 5012 (Brass Alloy)
BRASSALLOY (UNS C36000) per ASTM B 16
PropertiesofBRASSALLOY:
Chemical composition: Cu 61.5%, Zn 35.4%, Pb 3.1%
Hardness as machined: 80-90 Rockwell B
Density: .307 lbs/in3
Electrical conductivity: 26% IACS*
Melting point: 900°C/885°C (liquidus/solidus)
(3 to 4% lead is used to permit "free machining" and is permitted by EC Directive 2002/95Annex 6; so all pin
materials are RoHS compliant)
*International Annealed Copper Standard, i.e. as a % of pure copper.
INSULATORINFORMATION:
PCT Polyester, (Thermx CG933, black)
High Temperature
PropertiesofPCTPolyester:
Brand: Thermx
Grade: CG-933
Rated voltage: 100 VRMS/150 VDC
Insulation resistance: 10,000 Megaohms min.
Material Heat Deflection Temp (per ASTM D 648): 529°F (276°C) @ 66 psi
Dielectric strength: 1000 VRMS min. (700 VRMS min. for series 117 Shrink DIP)
Mill-Max Mfg. Corp. Datasheet — Last Modified 6/6/2009
Page 1 of 2
