參數資料
| 型號： | 582-11-357-09-005414 |
| 廠商： | MILL-MAX MFG CORP |
| 元件分類： | 插座 |
| 英文描述： | BGA357, IC SOCKET |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 2/2頁 |
| 文件大小： | 254K |
| 代理商： | 582-11-357-09-005414 |
BRASSALLOY (UNS C36000) per ASTM B 16
PropertiesofBRASSALLOY:
Chemical composition: Cu 61.5%, Zn 35.4%, Pb 3.1%
Hardness as machined: 80-90 Rockwell B
Density: .307 lbs/in3
Electrical conductivity: 26% IACS*
Melting point: 900°C/885°C (liquidus/solidus)
(3 to 4% lead is used to permit "free machining" and is permitted by EC Directive 2002/95Annex 6; so all pin
materials are RoHS compliant)
*International Annealed Copper Standard, i.e. as a % of pure copper.
INSULATORINFORMATION:
FR-4 Laminate
High Temperature
PropertiesofFR-4Laminate:
Epoxy/Glass Laminate. Thicknesses available: .010", .020", .031", .047", .062", .093", .125" (natural color, beige)
ENVIRONMENTAL DATA:
Operating temperature range: -55/+125 °C
Shock (No electrical discontinuity greater than 1μs):50 G
Solderability: 364-52
Resistance to soldering heat: 364-56A Test Cond. C
Resistance to atmospheric corrosion: 364-22A/31A
Climactic category (IEC): 365-17A
- Nitric Acid Vapor Test: 365-17A
Vibration (No electrical discontinuity greater than 1s): 10-2000 HZ, 15 G
Mill-Max Mfg. Corp. Datasheet — Last Modified 6/5/2009
Page 2 of 2
