Card Edge Connectors
.125, .156 Centerline Connectors (Modified Fork)
583355-2
(Tyco Electronics P/N: 583355-2)
Document links for this part cannot be displayed. Your browser does not support inline frames or
is currently configured not to display inline frames. Inline frames are supported in both Internet
Explorer 5 and Netscape 6, as well as all later versions of these browsers.
Related Part Information
General Information
eCommerce
Related Part Information
Searchable Features:
Brand:
AMP
RoHS/ELV
Compliance:
Non-compliant
Lead Free
Solder Process:
Wave solder
capable to
240°C
Product Type:
Connector
Assembly
No. of Positions: 15
Post Styles:
Solder Tail
Housing Style:
With Mounting
Ears
Other Properties:
Material:
Glass-Filled Polyester, Glass-Filled
Nylon
Contact
Material:
Phosphor Bronze
Contact Mating
Area Plating:
Gold (15) over Nickel
Color:
Black
Comment:
A 1.57 [.063] thick dummy pc board
should be inserted into connectors
during soldering to a motherboard.
Visit Tyco International, Ltd.
