Only One Name Means ProTek’Tion
www.protekdevices.com
05016.R5 2/11
Page 2
05016
587B051 - 587B301
tyPical Device chaRacteRistics
MaXiMuM Ratings @ 25°c unless otherwise specified
PaRaMeteR
syMBol
value
units
Operating Line Voltage: +10%
V
O
130
Volts AC
Line Current: 587B051/587B151/587B201/587B301
-
5/15/20/30
Amps
Peak Transient Voltage
-
6000
Volts
Peak Transient Current
-
3000
Amps
Current Leakage @ 130 Volts AC: Line-to-Neutral & Neutral-to-Ground
-
1 & 0.5
mA
Operating Temperature - Note 1
T
A
-40 to 85
°C
Storage Temperature - Note 1
T
STG
-40 to 85
°C
notes
1. Measured at the center of the mounting surface.
electRical chaRacteRistics @ 25°c unless otherwise specified
PRotection
MoDe
(note 1)
MaXiMuM
claMPing voltage
(note 2)
volts
oPen ciRcuit
voltage
(note 2)
@1.2/50s
volts
shoRt ciRcuit
cuRRent
(note 2)
@ 8/20s
aMPs
Line to Neutral
295
1000
500
Line to Neutral
350
6000
3000
Neutral to Ground
500
1000
500
Neutral to Ground
650
6000
3000
notes
1. Differential Mode Protection: Line to Neutral. Common Mode Protection: Neutral to Ground.
2. Test condition responses to transient voltages.
FilteR chaRacteRistics (noise attenuation db)
Frequency (MHz)
0.15
0.5
1.0
5.0
10
30
Common Mode Attenuation
10
25
35
55
50
40
Differential Mode Attenuation
30
55
50
45
