參數資料
| 型號： | 5962-0623502QPX |
| 廠商： | INTERSIL CORP |
| 元件分類： | 音頻／視頻放大 |
| 英文描述： | 1 CHANNEL, VIDEO AMPLIFIER, CDIP8 |
| 封裝： | CERAMIC, SBDIP-8 |
| 文件頁數： | 2/4頁 |
| 文件大小： | 116K |
| 代理商： | 5962-0623502QPX |
2
FN6472.1
May 11, 2007
IMPORTANT NOTE: All parameters having Min/Max specifications are guaranteed. Typ values are for information purposes only. Unless otherwise noted, all tests are
at the specified temperature and are pulsed tests, therefore: TJ = TC = TA
Absolute Maximum Ratings (T
A = +25°C)
Thermal Information
Supply Voltage from VS+ to VS-. . . . . . . . . . . . . . . . . . . . . . . . . 5.5V
Input Voltage . . . . . . . . . . . . . . . . . . . . . . . . VS+ +0.3V to VS- -0.3V
Differential Input Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2V
Continuous Output Current . . . . . . . . . . . . . . . . . . . . . . . . . . . 20mA
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60.5mW
Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . -65°C to +150°C
Ambient Operating Temperature . . . . . . . . . . . . . . . -55°C to +125°C
Operating Junction Temperature . . . . . . . . . . . . . . . . . . . . . . +150°C
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
Electrical Specifications
VS+ = 5V, VS- = GND, TA = +25°C, VCM = 2.5V, RL to 2.5V, AV = 1, Unless Otherwise Specified
PARAMETER
DESCRIPTION
CONDITIONS
MIN
TYP
MAX
UNIT
INPUT CHARACTERISTICS
RIN
Input Resistance
Common Mode
3.5
M
Ω
CIN
Input Capacitance
0.5
pF
OUTPUT CHARACTERISTICS
ROUT
Output Resistance
AV = +1
30
m
Ω
ENABLE (5962-0623501QPC ONLY)
tEN
Enable Time
200
ns
tDS
Disable Time
25
ns
AC PERFORMANCE
BW
-3dB Bandwidth
AV = +1, RF = 0Ω, CL = 5pF
500
MHz
AV = -1, RF = 1kΩ, CL = 5pF
140
MHz
AV = +2, RF = 1kΩ, CL = 5pF
165
MHz
AV = +10, RF = 1kΩ, CL = 5pF
18
MHz
BW
±0.1dB Bandwidth
AV = +1, RF = 0Ω, CL = 5pF
35
MHz
Peak
Peaking
AV = +1, RL = 1kΩ, CL = 5pF
1
dB
GBWP
Gain Bandwidth Product
200
MHz
PM
Phase Margin
RL = 1kΩ, CL = 5pF
55
°
SR
Slew Rate
AV = 2, RL = 100Ω, VOUT = 0.5V to 4.5V
600
V/s
tR
Rise Time
2.5VSTEP, 20% to 80%
4
ns
tF
Fall Time
2.5VSTEP, 20% to 80%
2
ns
OS
Overshoot
200mV step
10
%
tPD
Propagation Delay
200mV step
1
ns
tS
0.1% Settling Time
200mV step
15
ns
dG
Differential Gain
AV = +2, RF = 1kΩ, RL = 150Ω
0.01
%
dP
Differential Phase
AV = +2, RF = 1kΩ, RL = 150Ω
0.01
°
eN
Input Noise Voltage
f = 10kHz
12
nV/
√Hz
iN+
Positive Input Noise Current
f = 10kHz
1.7
pA/
√Hz
iN-
Negative Input Noise Current
f = 10kHz
1.3
pA/
√Hz
5962-0623501QPC, 5962-0623502QPC
