SCD8518 Rev D
FEATURES
32 Channels provided by two independent 16-channel multiplexers
Radiation performance
- Total dose:
150 krads(Si), Dose rate = 50 - 300 rads(Si)/s
- SEU:
Immune up to 90 MeV-cm2/mg
- SEL:
Immune by process design
Full military temperature range
Low power consumption < 30mW
Two address busses (A0-3 & B0-3), and two enable lines afford flexible organization
All channel Inputs protected by ±20V nominal transorbs
Fast access time < 500ns typical
Break-Before-Make switching
High analog input impedance (power on or off)
Designed for aerospace and high reliability space applications
Packaging – Hermetic ceramic
- 96 leads, 1.32"Sq x 0.20"Ht quad flat pack
- Typical Weight 15 grams
DSCC SMD 5962-09204 pending
ACT8518 32-Channel Analog Multiplexer Module
Radiation Tolerant & ESD Protected
GENERAL DESCRIPTION
Aeroflex’s ACT8518 is a radiation tolerant, 32 channel multiplexer MCM (multi-chip module) with
electrostatic discharge (ESD) protection on all channel inputs.
The ACT8518 has been specifically designed to meet exposure to radiation environments. It is available in
a 96 lead High Temperature Co-Fired Ceramic (HTCC) Quad Flatpack (CQFP). It is guaranteed
operational from -55°C to +125°C. Available screened in accordance with MIL-PRF-38534, the ACT8518
is ideal for demanding military and space applications.
ORGANIZATION AND APPLICATION
The ACT8518 consists of two 16 channel multiplexers arranged as shown in the Block Diagram. The
ACT8518 design is inherently radiation tolerant.
A SECTION
Sixteen (16) channels addressable by bus A0~A3, in one 16 channel block including enable.
B SECTION
Sixteen (16) channels addressable by bus B0~B3, in one 16 channel block including enable.
www.aeroflex.com/mux
Standard Products
November 18, 2008
Note: Aeroflex Plainview does not currently have a DSCC certified Radiation Hardened Assurance Program.
