For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
General Description
The MAX4599 single-pole/double-throw (SPDT) switch
operates from a +2.0V to +5.5V single supply. It offers
60 max on-resistance (RON) at +5V and fast switching
times (tON = 30ns max, tOFF = 25ns max).
The MAX4599 features excellent RON flatness (4 max)
and matching (1 max) between channels. This device
also offers 5pC max charge injection.
The MAX4599 is available in tiny 6-pin SC70, DFN, and
SOT23 packages.
Applications
Battery-Operated Equipment
Audio and Video Signal Routing
Cellular Phones
Low-Voltage Data-Acquisition Systems
Sample-and-Hold Circuits
Communications Circuits
Features
Available in 6-Pin SC70 Package
60 max (40 typ) On-Resistance
1 max (0.2 typ) RON Matching Between
Channels
4 max (2.5 typ) RON Flatness
Fast Switching: tON = 30ns (max)
tOFF = 25ns (max)
Guaranteed 5pC max Charge Injection
+2.0V to +5.5V Single-Supply Operation
200MHz -3dB Bandwidth
Low ±0.5nA Leakage Current at +25°C
Break-Before-Make Switching
TTL/CMOS-Logic Compatible
-76dB Off-Isolation at 1MHz
0.12% Total Harmonic Distortion
MAX4599
Low-Voltage, Single-Supply,
SPDT Analog Switch in SC70
________________________________________________________________ Maxim Integrated Products
1
SC70-6/DFN-6/SOT23-6
5
4
16
2
3
NO
COM
NC
GND
V+
IN
MAX4599
MAX4599
IN
0
NC
ON
NO
OFF
1OFF
ON
SWITCH IS SHOWN FOR "0" INPUT.
19-1637; Rev 2; 2/04
Pin Configuration/Functional Diagram/Truth Table
Ordering Information
PART
TEMP RANGE
PIN-
PACKAGE
TOP
MARK
MAX4599EXT-T
-40°C to +85°C
6 SC70-6
AAF
MAX4599EUT-T
-40°C to +85°C
6 SOT23-6
AAHC
MAX4599ELT-T
-40°C to +85°C
6 DFN-6
AA
