MAX4715/MAX4716
0.4
, Low-Voltage, Single-Supply
SPST Analog Switches in SC70
_______________________________________________________________________________________
3
ELECTRICAL CHARACTERISTICS—Single +1.8V Supply
(V+ = +1.8V, VIH = +1V, VIL = +0.4V, TA = TMIN to TMAX, unless otherwise noted. Typical values are at TA = +25
°C.) (Notes 2, 3)
PARAMETER
SYMBOL
CONDITIONS
TA
MIN
TYP
MAX
UNITS
LOGIC INPUT
Input Voltage Low
VIL
0.5
V
Input Voltage High
VIH
1.4
V
Input Leakage Current
IIN
VIN = 0 or V+
-1
1
A
SUPPLY
Power-Supply Range
V+
1.6
3.6
V
+25
°C
0.04
0.2
Positive Supply Current
I+
V+ = +3.6V, VIN = 0 or V+
TMIN to TMAX
2
A
PARAMETER
SYMBOL
CONDITIONS
TA
MIN
TYP
MAX
UNITS
ANALOG SWITCH
Analog Signal Range
VCOM, VNO,
VNC
0V+
V
+25
°C
0.6
1.2
On-Resistance
RON
ICOM = 10mA,
VNO or VNC = 0.9V
TMIN toTMAX
2.5
+25
°C-1
1
NO or NC Off-Leakage Current
INO(OFF)or
INC(OFF)
VCOM = 0.3V, 1.5V, VNO or
VNC = 1.5V, 0.3V
TMIN toTMAX
-10
10
nA
+25
°C-1
1
COM Off-Leakage Current
ICOM(OFF)
VCOM = 0.3V, 1.5V, VNO or
VNC = 1.5V, 0.3V
TMIN toTMAX
-10
10
nA
+25
°C-2
2
COM On-Leakage Current
ICOM(ON)
VCOM = 1.5V, 0.3V, VNO or
VNC = 1.5V, 0.3V, or floating
TMIN toTMAX
-10
10
nA
DYNAMIC
+25
°C18
25
Turn-On Time
tON
VNO or VNC = 1.5V, RL = 50
,
CL = 35pF, Figure 1
TMIN toTMAX
30
ns
+25
°C9
20
Turn-Off Time
tOFF
VNO or VNC = 1.5V, RL = 50
,
CL = 35pF, Figure 1
TMIN toTMAX
25
ns
Charge Injection
Q
VGEN = 0, RGEN = 0,
CL = 1nF, Figure 2
+25
°C40
pC
ELECTRICAL CHARACTERISTICS—Single +3V Supply (continued)
(V+ = +2.7V to +3.6V, VIH = +1.4V, VIL = +0.5V, TA = TMIN to TMAX, unless otherwise noted. Typical values are at V+ = +3.0V and
TA = +25°C.) (Notes 2, 3)
