參數資料
| 型號： | 5962-8997301PA |
| 廠商： | NATIONAL SEMICONDUCTOR CORP |
| 元件分類： | 運算放大器 |
| 英文描述： | OP-AMP, 6000 uV OFFSET-MAX, CDIP8 |
| 封裝： | CERDIP-8 |
| 文件頁數： | 9/14頁 |
| 文件大小： | 314K |
| 代理商： | 5962-8997301PA |
Electrical Characteristics (Continued)
(A
V= +20, VCC = ±5V, RL = 100,Rf =1.5k; unless specified).
Symbol
Parameter
Conditions
Typ
Max/Min Ratings
(Note 2)
Units
Miscellaneous Performance
CMIR
Common Mode Input Range
For Rated Performance
2.8
>2.0
>2.5
V
IO
Output Current
60
>35
>50
mA
Note 1: “Absolute Maximum Ratings” are those values beyond which the safety of the device cannot be guaranteed. They are not meant to imply that the devices
should be operated at these limits. The table of “Electrical Characteristics” specifies conditions of device operation.
Note 2: Max/min ratings are based on product characterization and simulation. Individual parameters are tested as noted. Outgoing quality levels are determined
from tested parameters.
Note 3: AJ-level: spec. is 100% tested at +25C.
Typical Performance Characteristics (T
A = 25, AV = +20, VCC = ±5V, RL = 100: Unless
Specified).
Non-Inverting Frequency Response
DS012744-1
Inverting Frequency Response
DS012744-2
Frequency Response for Various R
Ls
DS012744-3
Open-Loop Transimpedance Gain, Z(s)
DS012744-4
CLC401
www.national.com
4
