Electrical Characteristics (Continued)
(A
V = +32, VCC = ±5V,RL = 100,Rf = 1.5,VH = +3V; unless specified)
Symbol
Parameters
Condition
Typ
Max & Min Ratings(Note 2)
Units
Static, DC Performance
DIBN
Average Temperature
Coefficient
100
<150
–
<100
nA/C
IBI
Input Bias Current(Note 3)
Inverting
10
<46
<30
<40
A
DIBI
Average Temperature
Coefficient
100
<200
–
<100
nA/C
PSRR
Power Supply Rejection Ratio
70
>55
>60
dB
CMRR
Common Mode Rejection Ratio
70
>55
>60
dB
ICC
Supply Current(Note 3)
No Load
18
<25
<24
mA
Miscellaneous Performance
RIN
Non-Inverting Input
Resistance
150
>50
>100
k
CIN
Capacitance
4
<7
<7pF
RO
Output Impedance
at DC
0.2
<0.3
CMIR
Common Mode Input Range
3.0
>2.0
>2.5
V
VO
Output Voltage Range
No Load
±3.5V
>±3.0
>±3.2
V
IO
Output Current
40C to +85C
±60
>±35
>±50
mA
IO
55C to +125C
±60
>±30
>±50
mA
Note 1: “Absolute Maximum Ratings” are those values beyond which the safety of the device cannot be guaranteed. They are not meant to imply that the devices
should be operated at these limits. The table of “Electrical Characteristics” specifies conditions of device operation.
Note 2: Min/max ratings are based on product characterization and simulation. Individual parameters are tested as noted. Individual parameters are tested as
noted. Outgoing quality levels are determined from tested parameters.
Note 3: AJ 100% tested at +25C, sample at +85C
Typical Performance Characteristics (T
A = 25, AV = +32, VCC = ±5V, RL = 100,Rf = 1.5,VH =
+3V, V
L = 3V)
Non-Inverting Frequency Response
DS012753-4
Inverting Frequency Response
DS012753-5
CLC501
www.national.com
4
