MICROCIRCUIT DATA SHEET
MNCLC410A-X REV 0A0
(Absolute Maximum Ratings)
(Note 1)
Supply Voltage (Vs)
+7V dc
Output Current (Iout)
70mA
Common Mode Input Voltage (Vcm)
+Vs
Differential Input Voltage (Vid)
5V
Disable Input Voltage (D I S pin)
+Vs
Applied Output Voltage when Disabled
+Vs
Maximum Power Dissipation (Pd)
(Note 2)
1.2W
Lead Temperature (soldering, 10 seconds)
+300 C
Junction Temperature (Tj)
+175 C
Storage Temperature
-65 C to +150 C
Thermal Resistance
Junction -to-ambient (ThetaJA)
TBD
Ceramic DIP
(Still Air)
(500 LFPM)
Junction -to-case
(ThetaJC)
TBD
Ceramic DIP
Package Weight
(Typical)
TBD
Ceramic DIP
ESD Tolerance
(Note 3)
1000V
ESD Rating
Note 1:
Absolute Maximum Ratings are limits beyond which damage to the device may occur.
Operating Ratings are conditions for which the device is functional, but do not
guarantee specific performance limits.
For guaranteed specifications and test
conditions see the Electrical Characteristics.
The guaranteed specifications apply
only for the test conditions listed.
Some performance characteristics may degrade
when the device is not operated under the listed test conditions.
Note 2:
The maximum power dissipation must be derated at elevated temperatures and is
dictated by Tjmax (maximum junction temperature), ThetaJA (package junction to
ambient thermal resistance), and TA (ambient temperature).
The maximum allowable
power dissipation at any temperature is Pdmax = (Tjmax - TA) / ThetaJA or the number
given in the Absolute Maximum Ratings, whichever is lower.
Note 3:
Human body model, 100pF discharged through 1.5K Ohms.
3
